RS2 WALL SAW
RS2 WALL SAW BLADE INFO

Max saw blade diameter 1600 mm
Max cutting depth with max Ø blade 715 mm
Max start Ø blade 830 mm

WEIGHT

Weight saw head incl motor 24.5 kg

SAW BLADE MOTOR

Integrated torque motor

MAX OUTPUT POWER

18 kW

MAX OUTPUT TORQUE

148 Nm

SPINDLE SPEED UNDER LOAD

570-1050 rpm

MAX TRAVEL SPEED MAX ARM ROTATION

2.6 m/min 2.4 rpm/min

IP CLASSIFICATION

IP67

PENTPAK 3
PENTPAK 3 LOW WEIGHT

13 kg

VERY ROBUST AND LOW MAINTENANCE

Waterproof, IP67

ROBUST AND REPAIRABLE CONNECTOR

Made in house for maximum durability.
Replace connector inserts easily with standard hand tools

ELECTRICAL SAFTEY FEATURES

Highest EMC level
Built in RCCD - Residual Current Breaker Type B

WE INNOVATE SO YOU CAN GET THE JOB DONE

We are not restricted by what has already been done

Therefore we think i new and untraditional ways. Innovative designs tempered by experience.

Our strength is to use advanced but reliable technical soultions. This, in combination with the possibilities given by sound engineering principles and modern simulation toools, creates products which are ahead in their field.

Possibilities and willingness to go outside traditional boundaries in the design process are key factors for innovative design.

Attention to detail

For us it is personal. Every person working at Tractive knows that his or her work and attention to detail has a direct impact on the product quality and thus customer satisfaction.

It is a great responsibility which is happily taken on by everybody and at every step of the process from design to after sales support.

TECH SPECS

Saw blade ø max
1600 mm (63")
Cutting depth max
715 mm (28")
Max start Ø blade
830 mm (33")
Weight saw head inlc motor
24.5 kg (54) lbs
Max output power
18 kW
Max output torque
148 Nm
Spindle speed under load
570-1050 rpm
Max travel speed
2.6 m/min

Revolutionary one-of-a-kind integrated torque motor.
Very high system efficiency means more power to the saw blade.

LOW WEIGHT

Very compact, high power machines RS2 wall saw weighs under 24.5 kg with max output power of 18 kW

SHORTER SETUP TIMES

Quick disconnect coupling for blade Easy fitting of blade

Only one connector Simple to connect and disconnect

Light weight, easy to fit blade guard Best protection and handling

BUILT FOR LOW MAINTENANCE

Designed with the customer in mind Less components
Very easy coil change
Connectors service needs only hand tools
Efficient slip clutches for all motors
Brushless feed motors

Only one connector Simple to connect and disconnect

Light weight, easy to fit blade guard Best protection and handling

HFi SYSTEM - Modular, powerful and light weight

RS2 - WALL SAW

RS2 wall saw weighs under 24.5 kg with max output power of 18 kW. Easy fitting of blade with quick connect coupling. Built for low maintenance with the customer in mind.

PENTPAK 3

Made in house for maximum durability. Weighs only 13kg. Replace connector inserts easily with standard hand tools. Highest EMC level. Built in RCCD - Residual Current Breaker Type B

HEAVY DUTY CORE DRILL WITH
VERY LARGE SPEED RANGE

TECHNICAL DATA

MAX DRILL BIT Ø 1000 MM

NOMINAL POWER 11 kW

MAX OUTPUT POWER 10 kW

SPINDLE SPEEDS 150 - 1800 RPM

WEIGHT WITH AUTOFEED 14.5 kg

MAX TRAVEL SPEED 2.6 m/min

IP CLASSIFICATION IP67
